Dissolved Ozone Analyzer

　　The disolved ozone electrodes use Clark membrane technology and consist of a three-sensor system of gold cathodes, silver anodes and silver reference electrodes. The polarization of the silver reference sensors by constant voltage serves to stabilize measurements, avoids interference with traditional two sensor systems and effectively reduces drift in measurements. The unique membrane structure makes sensor probes very durable. The dissolved ozone probe used an integrated removable membrane component, each of which was pre-positioned with film, electrolyte and simplified the cumbersome work of replacing new membrane and electrolyte, which took only a few seconds.

　　i. Dissolved ozone analyzer market/application

　　1. Treatment of drinking water

　　2. Wastewater treatment

　　3. Sterilization in the food and beverage industries

　　4. Water bottled/barrel sealed

　　5. Plasma bleaching

　　Pharmaceuticals

　　7. Cooled water

　　8. Semiconductor washing water

　　II. Characteristics of dissolved ozone analyzer

　　1. Online controllers that extend up to 4 channels

　　2. Provision of the six languages, including the text, for choice by users

　　3. Device solids may be upgraded via USB port site

　　4. 1,000 data sets can be recorded and downloaded via USB

　　Clark's spectral technique for the tri-electric poles

　　Persistence film, anti-fouling.

　　7. Pre-installed membrane components, which are simple to replace.

　　8. High-precision temperature compensation

　　9. Options for multiple subject materials
